ปั๊ม MAYGO NSE 3 HP Single Phase 220V. 2"

รหัสสินค้า : PU-MG-NSE250

 Materials

  • Engineering plastics made water inlet and outlet

  • Mechanical seal module material: Graphite/ Silicon Carbide

  • O-ring: NBR

  • Aluminium motor casing

 Working Condition

  • Working Temp: 5-50°C

  • Ambient temp: ≤ 40°C

  • Working pressure: 0.3MPa

  • Max Self-priming Height

  • 3 meters

 Morter

  •230/380V asynchronous two-pole motor

  • Protection class: IP55

  • Insulation class: F

  • Continuous operation capability

  • Built-in overheat protection short circuit device

Curve

Dimension
